Station 07–14 · 02 Module Stacking & Welding
Module Double-Speed Chain Conveyor
Transports and locates modules through every station.
- Load
- ≥ 200 kg
- Speed
- ≤ 20 m/min
- Length
- Per station count
What it does
- Transports and locates modules through every station.
- Comprises lifters, conveyor, stoppers and work pallets.
Design features
- Robust structure, easy maintenance
- Stops and lift-locators configurable per station
- Enclosed sides for dust protection, looks and safety
Key parameters
| Load | ≥ 200 kg |
|---|---|
| Speed | ≤ 20 m/min |
| Length | Per station count |
Where it sits on the line
07 Module stacking & pressing · 08 Terminal addressing · 09 NG rejection · 10 CCS / busbar placement · 11 Busbar laser welding · 12 Post-weld cleaning & inspection · 13 Module EOL test · 14 Module transfer
